Layher. More Possibilities. The Scaffolding System.

Castors

  • Castors for a wide range scaffolding applications
    Castors for a wide range scaffolding applications
  • Castors

    Layher’s extensive range of high-quality castors greatly increases the manoeuvrability of your rolling tower or mobile scaffolding system.

    blue-triangle-sw

    • German made. Built to last
    • High load bearing capacity
    • Extensive range
    • Scaffold castors
    • Double flange castors

  • Scaffold castors

    Easily reposition Shoring TG 60 towers with castors
    Easily reposition Shoring TG 60 towers with castors

    Castors for scaffolds and rolling towers are available in a standard 150mm and 200mm diameter and braked load capacities ranging from 4–12kN. They offer a typical height adjustment range of 0.3–0.5m and feature a twin braking system, which not only brakes the wheel, but the slewing ring as well.

    The castors’ concentric design places the spindle directly above the wheel bearing, which reduces wheel wear and transmits scaffolding loads directly to the support surface for greater overall stability.

    For special applications, such as sensitive support surfaces or work in explosive and other high-risk work areas, Layher also offers castors with a polyurethane coating.


  • Castors used with Layher Allround Modular Scaffolding System
    Castors used with Layher Allround Modular Scaffolding System

  • Height adjustable scaffold castor with brake
    Height adjustable scaffold castor with brake
  • For capacities up to 12 kN
    For capacities up to 12 kN


  • Steel flange castors

    Layher’s double flange castors are extremely high-load bearing and designed for rail guided applications, such as material trolleys or bugies.

    They are available in diameters ranging from 230–285mm and boast braked load capacities ranging from 20–31kN. Unlike plastic wheel castors, flange castors do not provide an integrated spindle and must be secured to the structure using bolts and the flange top plate.

  • Double flange castors
    Double flange castors



  • Steel castors supporting manoeuvrable scaffold
    Steel castors supporting manoeuvrable scaffold

  • Easily transport with storage pallet
    Easily transport with storage pallet
